Cables are usually used to connect the computer host to peripherals such as monitors, keyboards, mice, etc., and can also be used to connect electronic devices such as TVs and stereos. There are many types and specifications of the cables, so it is very important for the quality control of cables, and the use of vision measuring machine can be a good control of quality problems.

Customer Requirements: Detect the spacing, length and width, conductor spacing, margin, gold finger length and other dimensions of the flexible flat cable.

Solutions: According to customer requirements, we recommend the vision measuring machine Model MVA-322.

Features:

● XYZ three-axis CNC automatic precision control, precise positioning;

● India marble base and columns are used, which has good stability.

● Precision linear guides, griding ball screws and AC servo motors ensure the accuracy and stability of the motion system.

● 0.1um high-precision grating ruler to ensure the positioning accuracy and measurement accuracy of the system.

● High resolution digital camera meets the requirements for clear observation and precise measurements.

● 8.3X high-definition optics with precise zoom and only one pixel correction is required.

● Programmable 5-ring 8-zone LED surface light source and parallel LED contour light source system, which can intelligently realize 256 levels of brightness adjustment.

● iMeasuring series of auto vision measurement software is powerful and easy to operate.

The following results can be obtained using the vision measuring machine MVA-322 inspection:

The CCD detection system of Sinowon precision vision measuring machine is equipped with high-resolution industrial cameras and high-pixel industrial lenses. It solves the problems of various sizes and measurement sizes of cable products. It provides high-quality pictures for the calculation and processing of image software.

At the same time, the model of vision measuring machine can be customized according to customer requirements, which can monitor the quality of the product well and ensure stability and reliability.
