Name: Vacuum / Heating Type Small Coating Tester 1PH Laboratory Coating Machine 1600W
Brand: Hoyamo and Sinowon Inc
SKU: ST-5000AZX
Availability: InStock

Vacuum / Heating Type Small Coating Tester 1PH Laboratory Coating Machine 1600W

1 Sets

MOQ

Can be discussed

Price

Features Gallery Product Description Request A Quote

Features

Specifications

Code#: 752-432ZX

Coating Accuracy: Wire Rod 0.002mm/ Scraper 0.02m

Coating Speed: 1-5m/min

Coating Method: Wire Rod And Scraper

Vacuum Pump: Including

Effective Coating Size: 400*300mm

Machine Size: (800*380*410)mm

Machine Weight: About 44Kg

Coating Temperature: 0-150°

Highlight:

Vacuum Small Coating Tester

Heating Type Small Coating Tester

Laboratory Coating Machine 1600W

Basic Infomation

Place of Origin: Dongguan, China

Brand Name: SQP

Certification: CE/ROHS

Model Number: ST-5000AZX

Document: Sinowon&SQP Coating Testing...a1.pdf

Payment & Shipping Terms

Packaging Details: Plywood

Delivery Time: 30 work days

Payment Terms: L/C, T/T

Supply Ability: 100 Sets/Month

Gallery

Vacuum / Heating Type Small Coating Tester 1PH Laboratory Coating Machine 1600W

Product Description

Small Coating Tester(Vacuum/HeatingType) ST-5000AZX Vacuum Heating Type

Vacuum / Heating Type Small Coating Tester 1PH Laboratory Coating Machine 1600W 0

Vacuum / Heating Type Small Coating Tester 1PH Laboratory Coating Machine 1600W 2

Product Feature:

ST-5000A series is a small machine specifically designed for laboratories that uses one or more coatings to form a solid continuous film on a substrate.

It can be heated and controlled with a vacuum. The coating bed is a flat vacuum table. It can be used for coating experiments on any flat material such as paper, plastic, metal, PVC, PET, cloth, aluminum alloy plate metal, glass, cloth, and other flat materials.

Specifications:

Commodity	Small Coating Tester(Vacuum/Heating Type)
Model	ST-5000AZ Vacuum Type	ST-5000AX Heating Type	ST-5000AZX Vacuum Heating Type
Code#	752-432Z	752-432X	752-432ZX
Coating Accuracy	Wire rod 0.002mm/ scraper 0.02m
Coating Speed	1-5m/min
Coating Method	Wire rod and Scraper
Coating Temperature	Ordinary Temperature	0-150°
Blade Material	Made of stainless steel, the scraper can be lifted
Coating Length	It can be set according to the length of different materials
Coating Time	Digital display, different lengths, different speeds, time accuracy control
Vacuum Pump	Including
Effective coating size	400*300mm
Coating Rod	Length: 400MM Material/stainless steel (thickness can be changed freely), purchase according to specifications
Machine Size	(800380410)mm (WDH)
Machine Weight	About 44Kg
Environmental Requirements	Temperature: 5℃ to 35℃, relative humidity: ≤80%
Power supply	1PH,AC220V,50Hz,1600W
